HUZHOU DP TECHNOLOGY CO.,LTD
Products Features:
1. Simple design and installation
Selecting an drum motor only needs to know the four parameters of diameter, velocity, power and belt width. Unlike the combination of gearbox and drive
pulley, you must choose gearbox series, speed ratio, and drive pulley model, as well as coupling series and model.The installation of the drum motor does not
require bracket of gearbox and motor, also don’t need to adjust the concentricity of the equipment.
2. High efficiency
The transmission efficiency of the drum motor is 3% -5% higher than that of the gearbox + transmission drum combination.
3. Save space
The motor and reduce equipment are installed in the drum body to achieve maximum space savings. Very suitable for places with small spaces,
such as tunnels .......
4. Low environmental requirements
The drum motor is suitable for various harsh environments, such as high altitude, low temperature, high humidity and so on.
5. Excellent reduction gear
Hard gear surface; It adopts the fixed shaft reducer structure when power is less than 18.5KW; It adopts the planetary reducer structure the power is
greater than 18.5KW.
6. Functions such as backstop, brake, speed control, explosion protection can be added according to actual needs
